T600LM Series Locking Lever Toggle Switch

The TOOWEI T600LM series locking lever toggle switch provides pull-to-unlock operation for control panels where accidental switching needs to be reduced. The operator lifts the lever to release the mechanical lock before manually changing switch positions. This deliberate action helps guard against unintended operation when the lever is accidentally touched or knocked..

The series offers maintained and momentary toggle action. Maintained models stay in the selected position after release and require the lever to be lifted again before the next change. Momentary models require a pull-to-unlock action before manual actuation, then return automatically to their original position when released. No additional unlocking action is needed for the spring return.

T600LM switches are available in single-pole and double-pole configurations with two or three positions. Circuit options include ON-OFF, ON-ON, and ON-OFF-ON, along with momentary functions depending on the model. The housing provides electrical insulation and structural support for the switch assembly.

Potential applications include machinery control panels, test instruments, and process control equipment requiring deliberate manual selection. Maintained versions support operating mode selection and circuit changeover, while momentary versions provide temporary control commands with automatic return. Its combination of lever locking, selectable operating actions, and three terminal styles gives equipment designers.
